Label Printer and QZ Tray Setup

Modified on Thu, 2 Nov, 2023 at 1:47 PM





Label Printer and QZ Tray Setup

Does OrderPort assist customers with their label printer?

Yes. We don’t send them to UPS, FedEx, or Zebra to assist because this is something we can help solve. However, the setup does involve using UPS, FedEx, and the manufacturer's documentation.


Label Printer Set-up

First, you need to download the driver for your printer.

LP2844 and ZP450 are compatible with OrderPort and you need to go to UPS or FedEx to find your drivers. For additional support on the drivers go to the Zebra Knowledge Base to find your printer.

Next, Login to OrderPort Admin à Shipping à click your shipping carrier à change the printer format to ZPL or ZPII depending on your carrier.

  • If you are shipping with Vinoshipper go to the Vinoshipper module à open the Shipper Label Format à ZPL.


  • Restart your Computer after installing the drives to take full effect.

  • The official OrderPort suggestion is using the QZ Tray with the label printers. However, the GIF label format can be used to avoid the QZ Tray. It will use your computer's default printing software interface to do so. You still need the drivers installed. It may not fill the label out properly. You can mess with the interface merges, paper size, and scale.

  • A screenshot of a computer Description automatically generated


Nextwe need to download the QZ Tray. Please make sure you download the appropriate link based on your operating system.
A screenshot of a computer
Description automatically generated

Printing Labels

Make sure the QZ Tray is running à create/unrelease a shipping order à Fulfillment à open your carrier terminal à Click the printer you want to print to à “Print”.


Downloading Drivers for Windows through Zebra

Download the Driver Link:


Extract File "UPS_5_1_7_certified_w10": image

Run the "Setup" Zebra:



"Install Zebra Printer":


Find your printers driver and click "Next"


Select your Port (the USB port your printer is plugged into) then click next:


Finish:


Once the download is done go to Settings --> Printers & Scanners


Find your printer:




Make sure the printer is configured to the Correct Port:




Downloading Drivers for Mac through Zebra

Settings à Printers & Scanners à Delete the Zebra printer with the minus button à Plus button à Select the Zebra printer à Choose a Driver à Select Software à Zebra EPL2 Label Printer à Add. Note, that if EPL2 doesn't work, try the other Zebra drivers. In UPS settings we will use GIF for now.


A screenshot of a computer
Description automatically generated


A screenshot of a computer
Description automatically generated

A screenshot of a software Description automatically generated

A screenshot of a computer Description automatically generated
